120° 3600lm SMD2835 Surface Mounted Linear LED Lights Aluminum IP20
Measurement:
| Product name | FG03-3865-9P 36w |
| Housing material | Aluminum |
| Surface treatment | Powder coated |
| CCT | 3000K,4000K,5700K |
| LEDs | 2835SMD |
| LEDs Life Span | 50000H |
| Input Voltage | 220-240VAC 50/60Hz |
| Power supplier | Flicker-free |
| Luminous Efficacy(lm/w) | 90-100lm/W |
| Color Render (CRI) | RA≥80 |
| Optional features: | No dimming, 0-10Vdimmer, DALI dimmer selectable |
| IP Rated | IP20 |
| Beam Angle | 120° (PC) |
| Working Temp(℃) | Surrounding Ambiance Temperature -20°~55°Degree Celsius |
| Color Option(shell) | White, Black |
| Certification | CE, SAA |
| Limited Warranty | 3 Years |
Product Advantages:
1. We produce aluminum profile.
2. Good heat dissipation, anti-discoloration and anti-oxidation.
3. Be Certificated with CE SAA, also available for UL test.
4. Covers are available in clear, semi-clear, milky-white with pc material.
5. Brand-name materials are used for production.
6. The finished profiles can pass UL test.
Product Description:
• Input voltage 220-240VAC 50/60Hz.
• 90-100lm/w with pc cover, 36w.
• Down light.
• No dimming, 0-10V Dimming function, DALI dimmer selectable. No stroboscopic.
• Driver brand: Lifud.
• 80% more energy saving compared with fluorescent lamp.
• Recommend Mounting Height: 3~6m.
• Optional microwave sensor:25% 50%75% to100%.
• Choice CCT of 3000K, 4000K or 5700K.
• SAA CE Certification,3 years warranty.
• Widely used in or Corridor ,Office , School , Hospital , Library , Public Room , Utility and so on.
Feature:
1. Connect with seamless, form with line shape.
2. Product can be used hanging ,surface mounted, recessed installation.
3. Cap with PC plastic moulding , connect with PC cover with seamless which let the light can't run out.
4. Aluminum PCB with no-facula design, connection by rotate installing which conveniently and easily.
5. PC cover transmitting rate reach 86%, luminous reach 100lm/w.
6. IC driver. No flicker, No glaring.CIR ≥ 80.PF ≥ 0.9.
6. Product passed SAA CE certifications.
Installation methods:
1. Seamless and linkable.
2. Suspened wire.
3. Ceiling mounted.
4. Different angle corner option to make different shapes.
