CRI80 Energy Saving Library Aluminum Suspended LED Linear Light 0-10V Dimming 6000K 100 - 277V
Quick Details
| Model Number | FG03-58100-L/C |
| Brand Name | LED Fulgor |
| Voltage | 220-240VAC 50/60Hz |
| Material | Aluminum |
| LED Source | SMD3030 |
| LED Driver | Lifud |
| Power | 45w |
| Dimming | No dimming, 0-10Vdimmer, DALI dimmer selectable |
| Lighting Effect | 70-80lm/w |
| Color Temperature(CCT) | 3000K/4000K/5700K selectable |
| CRI (Ra>) | ≥80 |
| UGR | <16 |
| Luminous Flux | 3500lm |
| Housing | Aluminum White/Black |
| Beam Angle | 15°30°45°selectable |
| Working Temperatue | -20℃ to 55℃ |
| IP Rating | IP20 |
| Working Lifetime | 50000h |
| Warranty | 3-years |
| Dimension | L1186*W58*H100mm |
| Packing Size | Inner Box: L121*W12.3*H8.2cm Outter Box:L130*W26*H18cm 4pcs/CTNS |
Product Description:
1. The product passed SAA CE ROSH certifications.
2. Aluminum with no-facula design, connection by rotate installing which conveniently and easily.
3. Long life, small weight, small power consumption.
4. Input voltage 120-240v.
5. 0-10V Dimming function, No stroboscopic.
6. Recommend Mounting Height: 3~6m.
7. Choice CCT of 3000K, 4000K or 5700K.
Excellent extrusion aluminum, reliable LEDs, it has high light efficiency and uniform light distribution. It can be widely used as wall lighting for decoration. LED Linear Light is a new generation of eco-friendly Linear LED Luminaire not only have an exquisite design, but also offer maximum light output, exceptional illumination, and excellent energy savings. LED linear light is exclusively designed for the designer and architects with imagination and personal style.
Our Quality Guarantee:
All our products must accept 5 kinds of Checks during production:raw material check, Lights beads check, aluminum plate check, power supply check, and the finished products need to pass 24 hours aging test.
Applications:
Widely used in schools, offices, retail spaces, hospitals, garages, basements, workshops, workbench area, entertainment rooms, storage rooms, warehouse, equipment rooms, industrial workstations, workplace, showrooms etc.
Our quality control:
1. Raw material 100% check before production.
2. order must have a first sample and full check before the manufacturing process.
3. 100% check before aging.
4. 24 hours aging with 500 times on-off testing.
5. 100% final inspection before packing.
Warnings :
1. The operating temperature is -20℃ ~ 55℃.
2. Avoid strong acid and alkali objects around the working environment.
3. If the working environment is outdoor, please make the butt joint waterproof
